CVD Plates

We supply CVD plates as per the customers requirement. Our CVD plates are from 3×3 mm till 10×10 mm and in various thicknessstarting from 200microns till 500microns.

Make an enquiry
Category:

Description

Our High grade single crystal CVD plates are measured at utmost precision. Growth surface is polished accurately to produce best quality CVD diamonds.

The CVD plates are available for customer who sign yearly supply contract and subject to availability.

Additional information

Length

3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 9.0, 10.0

Height

3.0, 4.0, 5.0, 6.0, 7.0, 8.0, 9.0, 10.0

Thickness, mm

0.5

Type

Ila

Face orientation

(100)

Edge Orientation

(110)

Crystallography

Multi-sectorial

Roughness, Ra

~5 nm

Miscut

90 +/- 3 00B0

Parallelism

+/- 0.02

Lateral Tolerance, mm

+/- 0.05

Thickness Tolerance, mm

+/- 0.05

Edges

Ploshed

Edges Features, mm

< 0.02

Laser

Water-jet

Boron Concentration, ppb

~50

Nitrogen Concentration, ppb

~10

Dislocations density, cm2

~10 2-5

Thermal conductivity, Wt/mK

~2200

Absorption coefficient, cm-1

0.0045
